PVIH: 5 Digit Precision Universal Indicator

Description

	5 Digits
	TC / RTD / mV / Current / Voltage Inputs
	Easy to Use
	7 Segment LED Display (Red)
	24V Auxiliary Power Supply (Optional)
	Size: 48 x 96MM

Digits	: 5 Digit, 7 Segment LED Display
Display Height	: 0.56”
Resolution	: 1° / 0.1° for TC / RTD Only : Fixed Resolution: 1° for R / S Type TC : 1 / 0.1 / 0.01 / 0.001 for Analog Inputs
Temperature Units	: C / F Selectable
Inputs	Universal (Factory Set)
Indication Accuracy	: ±0.25% ± 1° (TC Inputs) : ±0.1% ± 1° (RTD Inputs) : ±0.5% ± 1 (Analog Inputs)
Auxiliary Power	: 24V DC, 30 mA
Supply Voltage	: 85 to 270V AC / DC (50 / 60Hz) : 24VDC (Optional Supply)
Temperature	: 0 to 50°C (Operating)
Weight	: 200 gms
Protection	: IP65 (Faceplate)
Housing	: Fireproof ABS Enclosure
