PGSD : Schaeffer Diaphragm Type Pressure Gauge
|
Description
Special Features :
- Stainless steel case.
- Suitable for gaseous & liquid media.
- Ranges from -1 to 25 kg/cm2.
- Standard followed in general en 837 – 3.
Applications :
Chemicals / Refinery / Fertilizer / Petrochemicals / Pharmaceutical / Power / Cement / Sugar / Food & Beverages / Pulp & Paper & Allied Process Industries.
Additional information
| Accuracy | : ±1.6% of F.S. |
|---|---|
| Ambient temperature | : – 25°C to + 65°C |
| Process temperature | : Max 120°C |
| Operating pressure | : 75 % of the Range Value |
| Over pressure limit | : 130 % of Full Scale |
| Case | : AISI 304 SS |
| Ring | : AISI 304 SS Bayonet Type |
| Top Chamber | : AISI 304 SS |
| Bottom Chamber | : AISI 31 6 SS |
| Movement | : AISI 304 SS |
| Diaphragm | : AISI 316L SS |
| Protection | : IP 65 |
| Dial | : Aluminium, black graduation on white background |
| Pointer | : Aluminium, black coloured micrometer zero adjustable |
| Window | : Sheet Glass |
| Blow off Disc | : Neoprene |
| Gasket | : Neoprene |
