L110 : Light transmitter
|
Description
Key Points :
 |
Range from 0 to 10000 lux |
|
0-10 V active output, power supply 24 Vac/Vdc (3-4 wires) or 4-20 mA output, passive loop, power supply from 16 o 30 Vdc (2 wires) |
|
ABS V0 IP65 housing, with or without display |
|
“¼ turn” system mounting with wall-mount plate |
|
Housing with simplified mounting system |
Features :
|
Material | : | ABS V0 as per UL94 |
|
Protection | : | IP65 |
|
Display | : | LCD 10 digits. Size : 50 x 17 mm |
|
Height of digits | : | Values : 10 mm ; Units : 5 mm |
|
Cable gland | : | For cables Ø 8 mm maximum |
|
Weight | : | 140 g |
|
Environment | : | Air and neutral gases |
Additional information
| Output / Power supply | : active 0-10 V (power supply 24 Vac/Vdc ± 10%), 3-4 wires |
|---|---|
| Consumption | : 2 VA (0-10 V) or max. 22 mA (4-20 mA) |
| Electromagnetical compatibility | : EN61326 |
| Electrical connection | : Screw terminal block for cables Ø0.05 to 2.5 mm² |
| PC communication | : USB-mini Din cable |
| Environment | : Air and neutral gases |
