DPG2 : Differential Pressure Gauge
|
||||||||||||||||||||||||
Description
Special Features
- Simple and compact design.
- High operating pressure up to 200 bar.
- Overpressure safe from either side to maximum working pressure.
- Indicating mechanism isolated from the pressure chamber.
Applications
Filters, Hydraulic Systems, Water Treatment Plants, Chemical Plants, Natural Gas Processing, Heat Exchangers, Gasoline /Diesel Engine Filters, Pumps & Valves, Compressors.
Additional information
| Standard Version | : 63mm, 80mm, 100mm, 125mm, 150mm |
|---|---|
| Accuracy | : ±3% of F.S. |
| Ambient temperature | : – 25°C to + 65°C |
| Process temperature | : Max. 80°C |
| Case | : AISI 304 SS |
| Wetted Parts | : AISI 304 SS, Spring & Screw with Ceramic magnet |
| Body | : Aluminium |
| Protection | : IP 55 |
| Dial | : Aluminium, black graduation on white background |
| Pointer | : Aluminium, black Coloured, Fixed |
| Window | : Acrylic Glass |
| Seals | : Buna-N |
